Device Overview and Operation The cassettes
01750060162 A Cash Media Dispenser Version 4 - Service Manual 3-9
Reject / retract cassette
2
3
4
5
6
7
1
1
Box lid 5
Tamper indicator blue/green
2
Retract compartment lever 6
Cassette handle
3
Retract compartment 7
Locking lever (optional lock)
4
Reject compartment
