Page #201 background imageLoading...
Page #201 background image
Pin Assignments CMD controller
01750060162 A Cash Media Dispenser Version 4 - Service Manual 8-19
CMD controller
Connectors at the left side of the controller:
X1 mechanichal thickness sensor
Dubox connector, 8-pin
(Reihe = 2466407537, Sohn = 2466410537)
Pin Designation
1+5V
2GND
3 Measuring input for the first analog Hall sensor
4GND
5+5V
6GND
7 Measuring input for the second analog Hall sensor
8GND
X2 shutter
JST pin connector model PHD, 2 x 10-pin, S20B-PHDSS (90°)
(Reihe = A3C40014865, Sohn = A3C40014864)
Pin Designation
1+24V
2 Last GND
3+12V
4GND
5 Release of energization of SM7 (24 V level) / phase + (open)
of M7
6 Direction of SM7 (24 V level) / phase - (closed) of M7
7 Gate input of DPS10
8 Gate input of DPS11
9 Gate input of DPS12 (reserve)
10 Measuring input for phototransistor of PS27 or PS26
(detection of cash removal) (PSR6)
