20
Example of an error message
”7 blinks – 1sec. pause – 2 blinks – 1 sec. pause – 1 blinks”.
1. There is an error on a local input.
2. The error is on input X9.1, to which a rain sensor might be connected.
3. The error is due to no connection to the sensor.
If there are more errors on the panel simultaneously, they are shown with priority, i.e., the error message for the most critical error is
shown first and repeated until rectified. Then the error message number 2 is shown and repeated as well until the error is rectified
etc.
Below table, list the most common errors.
Error message
1. Blink sequence
2. Blink sequence
3. Blink sequence
Number
of blinks
Error on
Number
of blinks
Error on or error type
Number
of blinks
Error type
1
System
1
Internal error (Watchdog reset)
2
Internal error (Program CRC)
3
Smoke
zone
1
Max temp. in the panel has
been exceeded – re-configure
and check the panel, see
section 13 for re-configuration
of the smoke panel
5
Actuator
1
X1 (actuator output)
1
Actuator configuration – check the actuators,
check the configuration, when using ±24V
standard actuators check the termination
2
Expected number of actuators, the found and
expected number of MotorLink
®
actuators
does not match – check actuator
connections
4
Internal error
6
WSK-
Link™
1
Bus
1
Closed ring – the standard version does not
allow break glass units connected in a closed
ring, check connection of break glass units
and disconnect the ring and re-configure
2
Problem on X5 (break glass unit) –
communication with the break glass unit
cannot be established
2
WSK
1
Problem (short circuit, cable problem or
termination) with break glass unit #2
connected to a break glass unit– check
connection of break glass unit and
termination smoke detector input
3
Offline break glass unit, one or more break
glass unit is offline – check and re-configure
4
Break glass unit sensor (smoke detector
connected to break glass unit) – check
connection between break glass unit, sensor
and end-module (termination)
5
The break glass unit version is too old –
break glass units must be renewed
7
Local
input
1
X6 (smoke detector)
1
Termination – check connection of detectors
as well as termination
2
X9 (rain sensor)
1
Termination – check connection of sensor as
well as termination
10
Power
supply
1
Internal error
2
Mains – check connection
3
Back-up batteries – check
connection or replace the
batteries
4
Max temp. in the panel has
been exceeded – re-configure
and check the panel, see
section 13 for re-configuration
of the smoke panel
5
Internal error
If other errors or an “Internal error” are indicated, please contact WindowMaster.
