Window Master CompactSmoke WSC 104 - Access Levels; Max Numbers of Actuators Per Motor Line and Panel

5
2.1.1 Access levels
Level
Access to
Who has access
1
Public
You can see the smoke ventilation panel and break glass
unit from the outside with the doors closed and locked
Everyone / General public
2
Operation
You can open the break glass unit and reset the system
Chosen person e.g., building facility manger with
a special key to break glass unit.
3
Configuration
You can open the panel house; manual operate the windows
as well as change the DIP switch settings.
Chosen persons with a special key and
authorized to re-configure and service the panel
e.g., a trained technician.
4
Maintenance
Administrative overall level: for operating as well as updating
with new software.
A trained technician, with access to the key to
the panel, authorized by WindowMaster to
upgrade the firmware of the panel and with a
computer running the upgrading application,
supplied by WindowMaster.
3 Max numbers of actuators per motor line and panel
The table shows the maximum number of actuators, which can be connected to the motor line / panel depending on the type of the
actuators.
Per WSC 104
± 24V Actuator
MotorLink
®
Actuator
1)
WMD 820-1
4
4
WMD 820-2
4
2
WMD 820-3
3
3
WMD 820-4
4
4
WMS 306-1
4
4
WMS 306-2
4
2
WMS 306-3
3
3
WMS 306-4
4
4
WMS 309-1
4
4
WMS 309-2
4
2
WMS 309-3
3
3
WMS 309-4
4
4
WMS 409 xxxx 01
2
0
WMS 409-1
2
4
WMS 409-2
2
2
WMU 831 / 836 / 851-1
4
4
WMU 831 / 836 / 851-2
4
2
WMU 831 / 836 / 851-3
3
3
WMU 831 / 836 / 851-4
4
4
WMU 861-1
4
4
WMU 861-2
4
2
WMU 861-3
3
3
WMU 861-4
4
4
WMU 842 / 852 / 862 / 882-1
2
2
WMU 842 / 852 / 862 / 882-2
2
2
WMU 863 / 883-1
1
1
WMU 864 / 884-1
1
1
WMX 503 / 504 / 523 / 526-1
8
4
WMX 503 / 504 / 523 / 526-2
8
2
WMX 503 / 504 / 523 / 526-3
6
3
WMX 503 / 504 / 523 / 526-4
8
4
