Window Master CompactSmoke WSC 104 - Accessories and Spare Parts

6
± 24V Actuator
MotorLink
®
Actuator
1)
WMX 803 / 804 / 813 / 814 / 823 / 826-1
4
4
WMX 803 / 804 / 813 / 814 / 823 / 826-2
4
2
WMX 803 / 804 / 813 / 814 / 823 / 826-3
3
3
WMX 803 / 804 / 813 / 814 / 823 / 826-4
4
4
WML 820/825
4
0
WML 860-1
4
4
WML 860-2
4
2
WML 860-3
3
3
WML 860-4
4
4
WMB 801/802
2)
max. 4A connected to the WMB
WMB 811 / 812 / 815 / 816 / 817 / 818
2+3)
4
2
1)
MotorLink™ actuators must be of the same type and with same configuration
2)
Do not exceed the total power consumption of the motor line
3)
When having two locking actuators on the motor line, it must be one of each type: 1 x WMB 811 and 1 x WMB 812, WMB 815 and WMB 816, or WMB 817 and WMB
818
4 Accessories and spare parts
Accessories
Back-up battery for WSC 104 – 3.4Ah (2 x WSA 003 per panel)
WSA 003
Break glass unit, primary, with data communication, PVC housing. With input for smoke detector
and comfort keypads. Only one unit per panel.
x = colour of the housing: 1=red, 2=yellow, 3=grey, 5=orange
WSK 501 000x
Break glass unit, primary, with data communication, metal housing. With input for smoke
detector and comfort keypads. Only one unit per panel.
x = colour of the housing: 2=yellow, 3=grey, 5=orange
WSK 502 000x
Break glass unit, primary, with data communication, PVC housing. No input for smoke detector
or keypad. Max five units per panel.
x = colour of the housing: 1=red, 2=yellow, 3=grey, 5=orange
WSK 503 000x
Break glass unit, primary, with data communication, metal housing. No input for smoke detector
or keypad. Max five units per panel.
x = colour of the housing: 2=yellow, 3=grey, 5=orange
WSK 504 000x
Smoke detector
WSA 311
Rain sensor
WLA 331
Rain/wind speed sensor
WLA 330
End of line motor module
WSA 514
End of line smoke detector module (10kΩ resistor), 10 pcs.
WSA 501
Cables for smoke ventilation – see separate data sheet for further information
WLL 8xx
Comfort keypad for 1 window or 1 window group
WSK 110 0A0B
Spare parts
4A power supply unit for WSC 104
WCA 1P1
Main card incl. cover
WSA 1SS
Replacement glass for break glass units’ type WSK 501 / 502 / 503 / 504, 5 pcs.
WSK 397
Keys for break glass units’ type WSK 501 / 503, 5 pcs.
WSK 398
Keys for break glass units’ type WSK 502 / 504, 1 pcs.
WSK 453
Lockable replacement PVC housing for break glass unit
x=colour of the housing: 1 = red, 2 = yellow, 3 = grey, 5 = orange
WSK 399 000x
