12
Operations
Technical Specifications
ITEM DIMENSION/CAPACITY
Weight 92lbs (42kg)
Length 41 inches (104cm)
Height 34 inches (86.4cm)
Width 17.5 inches (44.5cm)
Wheels (2) 10 in (25 cm) Diameter wheels by 2 in
Solution Spray 2 Quick Change Jets
Power Cable 50 Feet (12.7 m)
Vacuum Shoe 17 in (43.2 cm) cast aluminum with spring loaded down pressure.
Electrical 230-240 V, 7 A, 50 HZ
Electrical Vacuum Motor 3 stage, 1.5 hp, 100 cfm (2.80 cubic meters/min.), Waterlift 121 inches (304 cm)
Brush 15 inch (38.1 cm.)
Brush Speed 1000 rpm
Solution Pump 90 PSI, Diaphragm style, internal bypass
Solution Capacity 7 gallons (26.5ltr)
Recovery Capacity 7 gallons (26.5ltr)
8-640-407-0 Manual, Operators CDT7I - 230V
