23
Operations
Accessory Tool Usage
Use only one of the following acceptable accessory
tools.
8.600-061.0 - STANDARD WAND
8.600-006.0 - VSM DUSTING TOOL W/MTG CLIP
8.603-154.0 - HOSE ASM, CST HANDTOOL U19821
1. Pull back collar and insert over machine mounted
fitting, then release collar to lock into place.
2. Lift door on front of vacuum shoe and insert 1 ½
inch hose cuff into hole.
3. Turn on vacuum motor switch and set solution
switch to intermittent position.
NOTE: Be sure brush switch is in off position and
brush is in storage position.
4. Squeeze handle on accessory tool to begin
cleaning.
8-640-407-0 Manual, Operators CDT7I - 230V
