28
Maintenance
Solution Pump Replacement
Only qualified maintenance personnel are to
perform the following repairs.
Seul le personnel d'entretien qualifié peut effectuer
des réparations
1. Turn off all switches and unplug the machine.
2. Remove recovery tank.
3. Remove the (2) screws that fasten the solution
tank to the frame, and tilt tank back to expose the
inside of the frame.
4. Remove solution hoses from fittings in pump.
5. Remove the (2) screws that fasten the pump to the
frame.
6. Reverse process to install pump.
8-640-407-0 Manual, Operators CDT7I - 230V
Valve Asm
86258830
Diaphram
86235100
Pump Replacement Parts for Shurflo 100 psi (86026400)
Pump Head
86251040
Pressure
Switch
86161980
Pump Replacement Parts for Shurflo 100 psi (86026400)
