86333220 CS20 103
Solution Tank
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86326310 1 FITTING, ELBOW 3/4 BSP, O-RING
2 86326620 1 HOSE, 3/4ID X .12W X 20"LG, CLR
3 86330960 2 LANYARD, ELASTIC, .125 X 4.0
4 86233150 1 SP CLAMP, 3/8 HOSE (D-SLOT)
5 86329670 2 COVER, FILL PORT
6 86326280 1 BRACKET, TANK BRACE
7 86321270 1 HOSE, 3/8ID WIREBOUND X 18"
8 86317940 1 TANK, SOLUTION, CS20
9 86279630 5 WASHER, .344IDX1.130ODX.09T PLT
10 86010670 2 WASHER, 5/16 X 3/4 SS
11 86010610 1 VALVE, 24VDC SOL 3/8 HOSE CIM
12 86346040 1
VALVE, BALL 3/8MPT X 3/8BARB,
90DEG
13 86007970 1 STRAINER, 3/8 IN. NPT 60 MESH
14 86275180 4 SCR, 5/16-18 X 1/2 HHCS GR5
15 86006760 3 SCR, 5/16-18 X 3/4 HHCS GR5
16 OPEN - -
17 86233110 1 CLAMP, 1.00 WORM GEAR
18 86279600 2 WASHER, #6 FLAT BRASS
19 86333260 2 GASKET, 3.0”, FILL PORT
20 86328020 1 HOSE ASM, 1.25 ID X 14.0, 4:1
