86333220 CS20 117
Wiring-Battery
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1A 86329720 2 BATT, CBL, ASM, JUMPER
1B 86334280 2 CBL, 6GA 5/16" RING 15" NOT SHOWN
2A 86329710 1 BATT,CBL,ASM,W/ANDERSON
2B 86334270 1 CBL, BATT RING W/ANDERSON NOT SHOWN
3 86228400 3 BATTERY, 12V, 130AH
- 86328630 3 BATTERY, 12V 114A/H AGM NOT SHOWN
4 86270920 2 SP NUT, 6-32 HEX NYLOCK SS
5 86279450 2 WASHER, #6 FLAT SAE PLTD
6 86274710 2 SCR, 6-32 X 1.0 PPHMS
7 86271910 6 NUT, 5/16-18 FLEXLOCK NOT SHOWN
8 86006560 6 SCREW 5/16-18 X 1 HHCS SS NP NOT SHOWN
