86333220 CS20 71
Drive-Chain
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86330720 1 CHAIN TENSIONER
2 86329350 1 NUT, 1/4-20 X 7/8 HEX COUPLING SS
3 86329340 1 PLATE, CHAIN GUARD
4 86328050 2 WASHER, SHOULDER.48ID X 1.25OD
5 86005810 3 NUT, 1/4-20 HEX NYLOCK SS
6 86327110 1 BRACKET, CONNECTORS
7 86273100 3 SCR, 1/4-20X2-1/4 HXHD CAP
8 86322060 1 COLLAR, 12MM ID
9 86322050 1 SPROCKET, STEERING, 14T
10 86322040 1 PLATE, CHAIN RING
11 86322030 3 SPACER
12 86270830 7 NUT, 5/16-18 HEX NYLOCK SS
13 86319740 1 PLATE, UPPER CLAMP
14 86319680 1 PLATE, LOWER CLAMP
15 86319610 1 BRACKET, BEARING CLAMP
16 86319600 1 BRACKET, DRIVE MOUNT
17 86319590 1 SHAFT, STEERING SPROCKET
18 86319560 1 CHAIN, ISO O8B, 12.7MM PITCH
19 86014440 1 BEARING, DRIVE
20 86224270 1 SLEEVE, CHAIN TENSIONER
21 86259430 1 WASHER, 12.5 ID X 26 OD X 2T FLAT
22 86279510 1 WASHER, 3/8 X 1 FLAT NP
23 86010780 1 WASHER, 1/4 SPLIT
24 86010670 4 WASHER, 5/16 X 3/4 SS
25 86010630 7 WASHER, 1/4 X 5/8 FLAT SS
26 86233380 1 CLAMP, 3/8 CUSHIONED
27 86005710 3 NUT, 1/4-20 HEX W/STAR
28 86271930 1 NUT, 3/8-16 HEX NYLOCK SS
29 86276070 4 SCR, 5/16-18 X 3/4 CARRIAGE SS
30 86275190 1 SCR, 3/8-16 X 1.25 HHCS SS
31 86006800 2 SCR, 10-32 X 1/2 PHTR PLT
32 86274760 1 SCR, 1/4-20 X 1/2 HHCS
33 86274150 4 SCR, 1/4-20 X 1.75 HHCS
34 86232780 - CHAIN MASTERLINK 12.7MM
