Windsor chariot iScrub 20 CSXC20 User Manual

86333220 CS20 75
Frame & Rear Wheels
REF PART NO. QTY DESCRIPTION
SERIALNO.
FROM
NOTES
1 86326260 1 BRACKET, FRAME LEFT
2 86326250 1 BRACKET, FRAME RIGHT
3 86340610 1 ASM FRAME, CS20 INCLUDES ITEM 8 & 9
4 86326220 2
SPACER, FLG .887ID X 1.055D X
.345LG
5 86318030 1 AXLE, 20MM X 562 MM
6 86318020 2 WHEEL, PU 150MM X 40MM
7 86223470 2 RING, 20MM EXTERNAL SNAP
8 86279510 2 WASHER 3/8 FLAT
9 86340950 2 SCR, 3/8 X 1.5, LAG, PLTD
