86317500 CHARIOT SCRUBBER 73
Rear Cover
*See Serial Number Page
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86276780 70728 3 SCR, 5/16-18 X 3/4 HHCS SS
2 86279130 87083 5 WASHER, 5/16 SPLIT LOCK PLTD
3 86010670 87029 5 WASHER, 5/16 FLAT SS
4 86031780 - 1 COVER, REAR DELUXE
5 86005860 57273 2 NUT, 1/4-20 X 12MM HEX BARREL
6 86228980 09152 2 BEARING FLANGED .377ID X .505OD
7 86275870 70556 2 SCR, 1/4-20 X 1.5" PPHMS SS
8 86242140 72193 1 KNOB, 3/8 -16 X 1.5
9 86010770 87143 2 WASHER, 7/16ID X 1D X .08FLT SS
10 86248380 66433 1 PAD, FLAT LEANING
11 86005630 57022 1 NUT, 3/8-16 HEX NYLOCK THIN SS
12 860710300 140786 1 BRKT, ASSEMBLY, REAR COVER
13 86010780 87162 2 WASHER, 1/4 SPLIT LOCK
14 86271940 57299 2 NUT, 1/4-20 ACORN SS
15 86006560 70083 2 SCR, 5/16-18 X 1 HHCS SS
16 86066940 140891 1 BAR, COVER
17 86324320 - 1 REAR, COVER DELUXE, *(3)
18 86324640 - 1 HANDLE, CAM LATCH *(3)
19 86324760 - 1 PLATE, COVER LATCH *(3)
20 86010630 87013 2 WASHER, 1/4 ID X 5/8 OD SS *(3)
21 86324340 - 1 BRKT, REAR COVER *(3)
22 86005810 57245 2 NUT, 1/4-20 HEX NYLOCK SS *(3)
23 86324650 - 1 PAWL, HANDLE *(3)
