86317500 CHARIOT SCRUBBER 59
Control Panel
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86315470 1 METER, HOUR ICD
2 86005810 57245 2 NUT, 1/4-20 HEX NYLOCK SS
3 86271840 57285 3 NUT, 5/16-18 HEX NYLOCK THN SS
4 86271910 57295 1 NUT, 5/16-18 FLEXLOCK
5 86313900 - 2 RELAY, 5A, 24V, 4PDT
6 86273820 70019 2 SCR, 1/4-20 X 1.25 HHCS SS
7 86275760 70540 1 SCR, 5/16-18 X 1.00 HHCS GR8
8 86277480 70850 3 SCR, 5/16-18X1/2 PTHMS SS
9 86007190 72161 1 SWITCH, KEY DPST
10 86255900 73538 14 STANDOFF, 6-32 X 5/8 HEX NYL
11 86255910 73659 1 STANDOFF, 1/4-20 X 1.0 HEX INS
12 86008760 80682 1 CONNECTOR, BATTERY GRY, 175AMP
13 86332510 - 2 BOOT, SEAL PUSH BUTTON 11MM
14 86010670 87029 1 WASHER, 5/16 X 3/4 SS
15 86068850 140219 1 BRKT, CABLE ATTACH
16 86070720 140728 1 BRKT, BATT CONN BASIC
17 86295200 - 1 ASM, BUTTON, BLACK, W/BEZEL
18 86012670 - 1 METER, 36V BATTERY
19A 86315400 - 1 CONTROLLER, 2-STAGE, GEAR DRIVE DISK
19B 86318040 - 1 CONTROLLER, GEAR DRIVE CYL CYLINDRICAL
20 86292590 - 1 SWITCH, E-STOP AKW CHARIOT
21 86313820 - 1 SWITCH, ROTARY, 7 POSN
22 86273830 70020 1 SCR, 1/4-20 X 1/2 HHCS SS NP
23 86313950 - 1 SWITCH, SPDT 3 POSN MOM, ARROW
24 86314150 - 1 KNOB, SELECTOR
25 86315640 - 1 PANEL, CONTROL
26A 86316160 - 2 BREAKER, 18A, 250VAC, 32 VDC DISK
26B 86322490 - 2 BREAKER, 30A 250 VAC, 32 VDC CYLINDRICAL
27 86010780 87162 1 WASHER, 1/4 SPLIT LOCK PLTD
28 86292780 - 1 SWITCH, MICRO
29 86270990 57090 2 NUT, 10-32 HEX NYLOCK SS
To Next Page
