86317500 CHARIOT SCRUBBER 57
Bumper
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86270830 57023 4 NUT, 5/16-18 HEX NYLOCK SS
2 86197040 57264 4 NUT, 5/16-18 HEX ACORN
3 86276070 70593 2 SCR, 5/16-18 X 3/4 CARRIAGE SS
4 86276890 70752 6 SCR, 5/16-18X3/4 PTHMS SS
5 86010670 87029 4 WASHER, 5/16 X 3/4 SS
6 86279130 87083 4 WASHER, 5/16 SPLIT LOCK PLTD
7 86070730 140729 2 BRKT, BUMPER MOUNT, SIDE
8 86315790 - 1 BRKT, BUMPER MTG
9 86331120 - 1 BUMPER, LEFT, GREY
10 86331110 - 1 BUMPER, RIGHT, GREY
