11
Operations
Technical Specifications
all
SPECIAL NOTES:
The sound pressure level at the operator's ear was
measured to be 74dBA . This was a nearfield, broad-
band measurement taken on a carpeted floor. This
appliance contains no possible source of impact
noise. The instantaneous sound pressure level is
below 63 Pa.
The weighted root mean square acceleration at the
operator's arms was measured to be below 2.5m/s2 .
This was a tri-axial, third-octave-band measurement
made during normal operation on a composite tile
floor. The measurement and related calculations
were made in accordance with ANSI S3.34-1986.
This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowl-
edge, unless they have been given supervision or
instruction concerning use of the appliance by a
person responsible for their safety. Children should be
supervised to ensure that they do not play with the
appliance.
ITEM DIMENSION/CAPACITY
Rated Amperage (120V) 15 AMPS
Rated Amperage (230V) 7.5 AMPS
Brush Motor 0.5 HP (373 W)
Bag Capacity 792 in³ (13 L)
Brush Two 25.5 in. (647mm) by 4 in. (10 mm) diameter
Brush Speed (120 V) 1550 RPM
Brush Speed (230 V) 1350 RPM
Maximum flow rate of machine 129 cfm (61 L/sec)
Maximum suction of machine 20 inches of water ( 4.97 kPa)
Weight Empty 151 lbs (68 kg)
Tires 9.75 in. (247mm) non-marking
Frame Construction Powder coated steel
