Windsor NW - Page 25

2586011370 NUWAVE
Brush Deck
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86293390 8 SCR, M5 X .8 X 15 SHCS GR 10.9 BLK
2 86137300 8 WASHER, M8 FLAT DIN125A PLT
3 86173350 5 WASHER, M5, FLAT, ISO7089, SS
4 86290110 1 NOZZLE, VACUUM, DECK
5 86218140 2 GASKET, VAC NOZZLE
6 86270830 5 NUT, 5/16-18 HEX NYLOCK SS
7 86010670 5 WASHER, 5/16 FLAT SS
8 86292460 2 WELMENT, DECK LEVELING BRKT
9 OPEN - -
10 86010720 4 WASHER, M10 X 30 PLTD
11 86295960 4 SCR, M10 X 20 HHMS GR 8.8 PLT
12 86293380 4 SCR, 5/16-18 X 3/4 CARR GR 10.9
13 86012780 1 PULLEY ASM, 5MM HTD 22T
14 86277130 1 SCR, 5/16 X 1.00 CARRAGE SS
15 86293400 10 SCR, M5X12 SHCS GR 10.9 PLT
16 86293200 1 ASSY, JACK SHAFT DRIVE
17 86215230 1 BEARING, BRONZE FLANGED
18 86223520 3 RING, 28MM INT SNAP PHOSPHATE
19 86215530 1 BRACKET, BELT TENSIONER
20 86279130 1 WASHER, 5/16 SPLIT LOCK PLTD
21 86215310 1 BELT, TIMING, 5MM X 15MM X 575
22 86223310 1 PULLEY, 5MM HTD, 18T, 12.7ID
23 86223490 2 RING, 10MM EXT SNAP, DIN 471
24 86222890 1 PLATE, BRUSH DRIVE COVER
25 86172970 4 SCR, M5X12, PHLP PHMS, ISO 7046, SS
26 86223320 2 PULLEY, 32T, 5MM HTD
27 86223780 10 SCR, M4X8, SET, ISO4029, CP, BLK
28 86012790 2 ASSY, BRSH END CAP SHFT
29 86219400 1 HOUSING, BRUSH DRIVE
30 86216120 1 BRUSH, 25.5 X 4.0 OD, FRONT
31 86216110 1 BRUSH, 25.5 X 4.0 OD, REAR
32 86216750 1 CLAMP, WORM GEAR 40-64MM
33 86291140 1 PULLEY, MICRO-V, 1.125 OD
34 86217810 1 EXTRUSION, DUAL BRUSH DECK
35 86219410 1 HOUSING, BRUSH RELEASE CLIP
36 86293230 2 ASSY, BRSH END CAP SHFT
37 86172980 2 SCR, KA50X10, PT OHS, WN1412, PLTD
38 86224630 2 SPRING, BRUSH CLIP
39 86295970 4 WASHER, M10 EXT STAR LOCK
40 86173330 8 WASHER, M5 FLAT, ISO7093, SS
41 86224170 2 SHAFT, 6.2MM BRUSH DRIVE
