2986011370 NUWAVE
Control Panel
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86172640 1 NUT, M8, NYLOCK, ISO7040, SST
2 86173300 1 WASHER, M8, FLAT ISO7089, SST
3 86224730 1 SPRING, COMP, 12MM OD X 12.7MM
4 86215410 3 BOOT, CIRCUIT BREAKER MP/MB
5A 86348660 1 SWITCH, 2 POSN, BRUSH 230V ONLY
5B 86007130 1 SWITCH DPDT 2-POSITION ROCKER 120V ONLY
6 86225960 1 WELDMENT, ELECTICAL PANEL
7 86005700 2 NUT, 10-32 W/STAR
8 86221820 1 LIGHT, INDICATOR, RED, 120VAC
9 86218960 1 HOOK, UPPER, CORD
10 86223830 1 SCR, M8X40, SHCS, ISO 4762, SST
11A 86217150 1 CORD ASM, 14/3 SJT X 75' YLW
11B 86217160 1 CORD ASM, EURO 1.5 MM X 75 BLK
11C 86217170 1 CORD ASM, AUST 1.5MM X 75 BLK
12A 86215670 3 BREAKER, 8A VDE CIRCUIT 120V ONLY
12B 86215710 3 BREAKER, 5A VDE CIRCUIT 230V ONLY
13 86218290 4 GASKET, CONSOLE, HANDLE
14 86276820 3 SCR, 10-32 X 1/2 PTHMS BLK NP
15 86299320 1 LABEL, GROUND SYMBOL 230V ONLY
16 86010640 1 WASHER, #10 LOCK EXT STAR SS
