Windsor NW - Page 35

3586011370 NUWAVE
Frame
*CALL MANUFACTURER FOR SERIAL NUMBER.
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86274860 10 SCR. M8X20 HHMS
2 86137310 18 WASHER, M8 SPLIT LOCK
3 86137280 22 WASHER, M8 FLAT DIN125A PLT
4 86295660 1 WELDMENT, HANDLE BRACE
5 86295780 2 M8X40 HHCS GR 8.8 PLT
6 86226050 2 WHEEL, 9.75" X 1.5”
7 86225730 2 WASHER, M6 (20.5 ODX1.6T) PLT
8 86173310 2 WASHER, SPRING LK, M6, DIN127B, SST
9 86293430 2 SCR, M6 X 16 HHMS GR 10.9 PLT
10 86219480 2 HUBCAP, 9.75 WHEEL
11 86293440 4 SCR, M8X25 HHCS BR 8.8 PLT
12 86228840 6 BEARING, FLANGED .314IDX.502OD
13 86215890 2 BRKT, SPRING ADJUST
14 86010720 2 WASHER, M10 X 30 PLTD
15 86259400 8 WASHER, THRUST .51 ID X 1 ODBRO
16 86224690 2 SPRING, .718OD X 3.41L X .091W
17 86223810 2 SCR, ADJUSTMENT DECK SPRING
18 86196610 6 NUT, M8 HEX NYLOCK
19 86216020 1 BRKT, DECK LINGAGE, LEFT
20 86218430 1 GUARD, BELT BRUSH DRIVE
21 86172980 2 SCR, KA50X10, PT OHS, WN1412, PLTD
22 86343450 2 SWIVEL CASTER, 3.7” *
23 86216010 1 BRKT, DECK LINKAGE, RIGHT
24 86005700 1 NUT, 10-32 W/STAR
25 86217980 1 FRAME, WELDMENT
26 86225970 1 WELDMENT, HANDLE BRKT, RIGHT
27 86225980 1 WELDMENT, HANDLE BRKT, LEFT
28 86010640 1 WASHER, #10 EXT STAR LOCK SS
29 86277530 8 SCR, M8X1.25 X 20 LG BSHCS SS *
