4386011370 NUWAVE
Wiring Diagram - 120V
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86266900 1 WIRE, 5" BLK/14 76029 X 76029
2 86268400 3 WIRE, 3" BLK/14 76029 X 76050
3 86218860 1 HARNESS, MAIN VACUUM
4 86267290 2 WIRE, 14" GRN/18 76008 X 76011
5 86268210 2 WIRE, 15" GRN/18 76008 X 76008
6 86218850 1 HARNESS, SWITCH VACUUM
7 86295540 2 WIRE, JUMPER, 130L X 14GA BLK
