8
Operations
Technical Specifications
ITEM DIMENSION/CAPACITY
Nominal power 1450 W
Rated Voltage 24VDC
Rated Amperage 60 Amps
Batteries 4 X 6 Volt 250-305-335 AH @ 20 hr rate
Scrub Brush Motors 2 X .75 hp (0.56 kW)
Vacuum Motor .75 hp (0.56 Kw)
Propelling Motor .3 hp (0.22 Kw)
Mass (GVW) 915 lbs. (415 kg) with 335 AH
Weight empty without batteries 346 lbs. (157 kg)
Solution Control
Gravity feed, fully variable with automatic shut-off in
neutral
Solution tank capacity 23 gal. (87 l)
Recovery tank capacity 25 gal. (95 l)
Scrub brush diameter for 26 in. (66 cm) scrub head 13 in (33.0 cm)
Scrub brush pressure
Mechanical 80 lbs. (356N) Floating 130 lbs. (578N)
restricted
Scrub brush speed 200 rpm
Tires 2 x 10 in (25.4 cm) non-marking foam-filled
Casters 2 X 4 in (10.2 cm) polyurethane solid non-marking
Foundation Pressure 21 lbs./in 2 (140 kPa)
Maximum Speed 3.2 Miles/hour (5.2 km/hour)
Frame Construction Steel plate with epoxy powdercoat finish.
Brakes (optional) Tire lock parking brake
Minimum aisle u-turn width with 26 in. (66 cm) scrub head 69 in. (175 cm)
Maximum rated climb and descent angle with empty
tanks and without optional parking brake
2%
Maximum rated climb and descent angle with full tanks
and without optional parking brake
2%
86039070 CUTTER 24V
