Winegard RD-9946 - Page 58

58
Model RD-9900
PINNACLE
POSITIONER
by WINEGARD
SELECT B
SELECT A
5. Press SELECT B Test
Remote Panel
Test LNB
Test Remote Panel
8. Press [SELECT A] Test Remote Panel, see Figure 12. The positioner will
read the elevation from the remote panel. See Figure 13; verify that elevation
is same as on remote panel.
Figure 11
Model RD-9900
PINNACLE
POSITIONER
by WINEGARD
SELECT B
SELECT A
6. Press SELECT A Test
Remote Panel
Test Remote Panel
Figure 12
Model RD-9900
PINNACLE
POSITIONER
by WINEGARD
SELECT B
SELECT A
Test Remote Panel
Elevation = XX
Figure 13
Elevation should be same
as selected by remote panel
