60
Model RD-9900
PINNACLE
POSITIONER
by WINEGARD
SELECT B
SELECT A
Test Remote Panel
Park LED = On
11. Press [LEFT] arrow button twice. Park LED will extinguish on remote
panel when Park LED = Off is displayed on positioner. See Figure 18.
Figure 17
Model RD-9900
PINNACLE
POSITIONER
by WINEGARD
SELECT B
SELECT A
Test Remote Panel
Search Key Pressed
12. Press [SEARCH] button twice. Search Key Pressed will be displayed on
positioner. See Figure 19.
Figure 19
Model RD-9900
PINNACLE
POSITIONER
by WINEGARD
SELECT B
SELECT A
Test Remote Panel
Park LED = Off
Figure 18
10. Press [RIGHT] arrow button twice. Park LED will light on remote panel
when Park LED = On is displayed on positioner. See Figure 17.
10. Press RIGHT arrow
button twice
11. Press LEFT arrow button
twice
