WINEMASTER WineC25 - Page 12

VERSION 2.1 06.2020
USER GUIDE WINE C25 / C25S(R)/WINEC25X/WINEC25S(R)X
Page 12
Flow from the condensate collection tray.
Push the PVC pipe on.
Pinch the collar to open it and slide it along the pipe
Place the collar as close to the pipe as possible
The pipe is well attached.
Refit the cover on the Winemaster and tighten the 4
screws
1
2
3
4
5
6
