SECTION 8
APPLIANCES & INTERIOR FEATURES
8-20
you must refit them when reverting back to
dinette seat configuration.
2. Release the catch on the table leg brace and
fold the leg up against the bottom of the
table.
3. Remove the table from the wall support
bracket by lifting the end of the table. Then
lower the table to rest on the cleats attached
to each dinette bench.
4. Arrange dinette cushions to cover bed area.
To Revert to Dinette:
1. Replace the table onto the wall support and
lower the table leg.
2. Make sure that the table leg is secured into
the floor support bracket and the leg brace is
locked.
Rest Easy
TM
Multi-Position Lounge -
Optional (If equipped)
To Recline: Press the bottom side of the
switch on the front of the armrest. Push the top
side to return to upright position.
Do not recline the lounge completely
flat unless the footrest section is
extended.
CAUTION
To Next Page
