SECTION 7
PLUMBING SYSTEMS
7-10
WATER SYSTEM DRAIN VALVE LOCATIONS
SYSTEM DRAIN VALVE LOCATIONS
Water Lines: One (1) valve in the front cargo compartment on the passen-
ger side of the coach.
Open exterior shower faucet and lay shower head on ground.
Also, to drain any water left in the city water line, place the
tip of your finger inside the city water connection and gently
press the backflow valve (small “button” in center of connec-
tor).
Water Tank: One (1) valve near the water tank in the cargo compartment to
the left (rear) of the entrance door on the passenger side of the
coach.
NOTE: On Model 38G the tank drain valve is in the compart-
ment behind the rear wheels on the passenger side of the
coach.
Water Heater: Drain plug on outside of coach, behind service door. Use
socket to remove drain plug.
Water Heater By-Pass Valve: By-pass valve is located in the front cargo compartment on
the passenger side of the coach.
Winterization (Antifreeze) Valve: Valve with clear vinyl siphon tube is located in the front cargo
compartment on the passenger side of the coach.
