Winny RoadRunner Plus User Manual

9
5.6 Charge the battery
5.6.1 Remove the cleaner from the pool
① Power off (no indictor flashes) the cleaner
② Attach the charging connector to the charging socket. The indicator lamp on the charger shall
turn red when charging. It should turn green once fully charged.
Note: Charge the cleaner indoor and at least 3m (appr. 10ft) from the edge of the pool for
charging.
5.6.2 Charger indicator
Colour & Status of indicator
Charging status
Green light is steady on
Waiting for a recharge or connector not plugged or
charging finished
Red light is steady on
The battery is being charged
Red light flashes
Low battery or battery damaged
Charging socket
LED Indicator
Red - Charging in Progress
Green - Fully Charged

Winny RoadRunner Plus Specifications

General

Rated input voltage of charger	100VAC-240VAC
Rated input frequency of charger	50Hz/60Hz
Maximum charging voltage	12.6VAC
Charging current	1.8A
Battery runtime	max. 90min
Battery capacity	8800mAh
Maximum cleaning surface	150m²
Filter density	180μm
Running speed	max. 11m/min (appr. 36ft/min), max. 11m/min (appr. 36ft/min)
Maximum pool depth	180μm
Optimal pool water temperature	10℃(50℉) - 35℃(95℉)
Charging environment temperature	5℃(50℉) -35℃(95℉)
Storage condition	5℃(50℉) -35℃(95℉), RH <75%

Weight and Dimensions

Robot size	360mm (L)408mm (W)240mm (H)
