Winny RoadRunner Plus User Manual

10
6.1 Initial operation
1. Make sure Bluetooth is active on your smartphone and download and activate the WYRobot
app (Get access to Bluetooth and location).
2. Push the power button forward, then bule light is on.
3. Push the power button backward and forward in 5 seconds, then purple light flashes.
4. Click on the search button. The app searches for and displays the serial number of the nearest
Winny robot.
5. Click on the Winny serial number displayed on your screen.
6. Set up the pool information and cleaning mode.
Settings
Shape
Size
Bottom
Cleaning Mode
Rectangle
Length
Flat
Pool floor only
Round
Width
Slope
Pool wall only
Oval
Diameter
Diamond
Once floor, once wall
Others
Depth
3 times floor, once wall
Section 6. Smartphone Control
Figure 6-1

Winny RoadRunner Plus Specifications

General

Rated input voltage of charger	100VAC-240VAC
Rated input frequency of charger	50Hz/60Hz
Maximum charging voltage	12.6VAC
Charging current	1.8A
Battery runtime	max. 90min
Battery capacity	8800mAh
Maximum cleaning surface	150m²
Filter density	180μm
Running speed	max. 11m/min (appr. 36ft/min), max. 11m/min (appr. 36ft/min)
Maximum pool depth	180μm
Optimal pool water temperature	10℃(50℉) - 35℃(95℉)
Charging environment temperature	5℃(50℉) -35℃(95℉)
Storage condition	5℃(50℉) -35℃(95℉), RH <75%

Weight and Dimensions

Robot size	360mm (L)408mm (W)240mm (H)
