Winny RoadRunner Plus User Manual

4
The robotic pool cleaner HJ3172 Plus is a new type of highly efficient and energy-saving
swimming pool cleaning robot. It cleans the pool walls and bottom automatically without
replacing the pool water. It is totally environmental-friendly.
For safe operation, the cleaner is powered by a rechargeable lithium battery (12.1V, 8.8Ah).
Item
Name
QTY (pc)
Remark
1
Cleaner
1
In carton
2
Charger
1
In plastic bag
3
Retrieving Hook
1
In plastic bag
4
User manual
1
In plastic bag
Section 1. Introduction
Section 2. Packing List
Section 3. Product Diagram
Filter Basket
Wheel
Top Cover
Power Button
Charger
Retrieving Hook

Winny RoadRunner Plus Specifications

General

Rated input voltage of charger	100VAC-240VAC
Rated input frequency of charger	50Hz/60Hz
Maximum charging voltage	12.6VAC
Charging current	1.8A
Battery runtime	max. 90min
Battery capacity	8800mAh
Maximum cleaning surface	150m²
Filter density	180μm
Running speed	max. 11m/min (appr. 36ft/min), max. 11m/min (appr. 36ft/min)
Maximum pool depth	180μm
Optimal pool water temperature	10℃(50℉) - 35℃(95℉)
Charging environment temperature	5℃(50℉) -35℃(95℉)
Storage condition	5℃(50℉) -35℃(95℉), RH <75%

Weight and Dimensions

Robot size	360mm (L)408mm (W)240mm (H)
