Requirements for on-site installation
Inlet water connection
Location approx. 500 mm above finished floor; to the right of the machine
Construction Isolation valve with G ¾” external thread
Inlet water temperature max. 60 °C
max. 20 °C PT Cool, PT EnergyPlus, PT ClimatePlus
Water quality Microbiologically, fresh water must be of drinking water quality
Water hardness Machines without in-
tegrated softener
Machines with integ-
rated softener
Note
PT Standard
PT Cool
≤ 3°dH (3.8°e /
5.34°TH / 0.54 mmol/l)
Recommended, so
that the warewasher
does not scale up.
≤ 31°dH (37.6°e /
53.4°TH / 5.35mmol/l)
-
PT EnergyPlus ≤ 3°dH (3.8°e /
5.34°TH / 0.54 mmol/l)
≤ 20°dH (25.1°e /
35.6°TH / 3.58mmol/l)
-
PT ClimatePlus ≤ 3°dH (3.8°e /
5.34°TH / 0.54 mmol/l)
- The conductivity must
be ≥200µS/cm (128
ppm TDS).
Water flow pressure 100 kPa (1.0 bar) PT Standard, PT Cool
150 kPa (1.5 bar) PT EnergyPlus, PT ClimatePlus
Max. inlet pressure (back
pressure)
600 kPa (6.0 bar)
Flow rate min. 4 l/min
Waste water connection
Location approx. 650 mm above finished floor; left or right of the machine
Dimensions Ø40 mm or 50 mm with trap
