1
Introduction
The machines of the UC Series are no longer distinguished by their
intended use but by their size.
The machine name is derived from the size:
UC-S replacing GS 202, 402
UC-M replacing GS 215
UC-L replacing GS 302, GS 310
UC-XL replacing GS 315
IMPORTANT: A machine of the UC Series can be used as glass,
dishes, bistro or cutlery washing machine in any size.
The programming is carried out at the first start-up and can be changed
anytime.
Alternatively, the machines are already programmed at the factory but
can be re-programmed on site.
Main dimensions of the 4 machines
UC-S UC-M UC-L UC-XL
Height
1
715 715 810 810
Width 460 600 600 600
Depth 602.5 602.5 602.5 641.5
Passage
height
308.5 308.5 403.5 403.5
Rack size
2
400x400 500x500 500x500 500x500
500x540
Dimensions in mm
1
In the machines with integrated exhaust air heat recovery (Energy) the
dimension of the height increases by 85 mm
2
Racks are not contained in the basic equipment of the machine
