Instructions condensing Air heaters type XR version XR-GB-4001-a Page 7/27
Type TR-4.5 (ERP2018) TR60 TR80 TR100 TR125 TR150
Maximum nominal heat input (Nett) kW 65,5 81,0 105,0 132,0 152,0
Minimum nominal heat input (Nett) kW 46,0 56,0 73,5 95,0 110,0
Maximum heat output kW
60,
8
7
4,
8
9
8,
3
12
1,
8
1
40,6
Minimum heat output kW 41,8 50,6 67,0 86,2 100,1
Efficiency max. power % 92,9 92,3 93,2 92,3 92,5
Efficiency min. power % 90,9 90,4 91,2 90,7 91,0
Max. air output (+temp. increase) m3/h 6600 8750 10.400 14.250 16.000
Throw horizontal (max.) m 28 30 30 33 35
Throw vertical (max. warm) m 6,0 6,0 6,0 6,0 6,0
Gas connection G” 3/4” 3/4” 3/4” 3/4” 3/4”
Electrical connection (50Hz) V 230 230 230 230 230
Electrical power consumption max. kW 0,350 0,600 0,750 1,100 1,500
Electrical power consumption min. kW 0,350 0,600 0,750 1,100 1,500
Electrical power consumption
standby.
kW 0,004 0,004 0,004 0,004 0.004
Electrical consumption Amps max. A 1,5 2,6 3,3 4,8 6,5
Emission efficiency, (ηs, flow) % 93,4 94,0 93,4 93,7 93,5
Seas. Space heating efficiency % 72,6 73,0 73,1 72.8 72,8
NOx emissie (GCV) mg/kWh 82 94 90 93 97
NOx klasse 4 4 4 4 4
Flue gas amount max. kg/h 120 150 200 250 310
Thermostat communication
bussystem (low voltage)
Argus Link
Pressure switch point Pa 180 180 220 215 200
Sound level dBA 50 52 54 60 63
Min. suspension height horz. throw M (min.) 1,7 1,7 1,7 1,7 1,7
Min. suspension height vertical. throw M (min.) 4,0 4,0 4,0 4,0 4,0
Maximum flue / air length m 9 9 9 9 9
weight kg 135 150 200 230 260
Na
t
ural gas G20 (I2H) , heater version 3.3
Nominal supply pressure G20 (H) mbar. 20
Supply pressure (min-max) G20 (H) mbar. 17-25
Gas category II2H3P B/P
Class B23, C13, C33
Max gas consumption G20 (H) m3/h 6,9 8,6 11,2 14,0 16,1
d injectors
n x Ømm
5x 3,2 6x 3,7 8x 3,7 9x 3,7 11x 3,7
d injectors
n x Ømm
1x 3,5 1x 3,5
Burner pressure high G20 (H) mbar 11,8 7,0 7,3 6,3 6,0
Burner pressure low G20 (H) mbar 5,8 3,3 3,4 3,1 3,1
CO2 High (indication) G20 (H) % 8,5 8,7 8,6 8,5 8,2
Propa
n
e
, G31,
heater version
3.4
Nominal supply pressure G31 (P) mbar. 30-50
Supply pressure (min-max) G31 (P) mbar. 25-50
Gas category II2H3P B/P
Class B23, C13, C33
Max gas consumption G31 (P) kg/h 5,2 6,4 8,4 10,5 12,1
d injectors
n x Ømm
5x 2,3 6x 2,3 8x 2,3 10x 2,3 12x 2,3
Burner pressure high G31(P) mbar 19,0 19,0 17,7 19,3 17,4
Burner pressure low G31(P) mbar 9,4 9,0 8,5 9,5 8,9
CO2 High (indication G31 (P) % 10,0 9,5 9,5 9,5 9,5
Buta
n
e
, G30
, heater
version
3.4
Nominal supply pressure G30 (B) mbar. 30-50
Supply pressure (min-max) G30 (B) mbar. 25-50
Gas category II2H3P B/P
Class B23, C13, C33
Max gas consumption G30 (B) kg/h 3,9 4,9 6,4 7,9 9,1
d injectors
n x Ømm
5x 2,3 6x 2,3 8x 2,3 10x 2,3 12x 2,3
Burner pressure high G30 (B) mbar 14,5 14,3 13,8 14,9 13,3
Burner pressure low G30 (B) mbar 7,4 6,0 6,5 7,5 7,1
CO2 High (indication G30 (B) % 9,2 9,2 9,2 9,5 9,5
