MRK16 INFO MENU
Expansion board Menu
Opt Exp
Board
Opt Rx acve
On/O
In: A:0.00mW / In: B: 0.00mW
RF signals levels
Serial
21700164
EXP3
1260-1610nm
1260-1610nm
0.20-2.00mW
0.20-2.00mW
+3v3 digital 3.32V
Exp board HW rev 0
PWR Supply temp. 43°C
+5_RF amplier 5.03V
Exp board opon
WL A
Model
WL B
RNG A
RNG B
Temp.
Supply
HW
Opt IN levels
RF Bars
Info
Use this menu to access information about the device, including its serial number, frequen-
cy range, firmware version, and hardware version. Additionally, you can monitor its status,
including voltage, temperature, and any alarms present.
Serial
The serial number uniquely identifies the unit and consists of 8 characters.
FW
This displays the current firmware version installed on the device.
HW
Shows the hardware revision of the unit.
Diagnostic
This menu provides information about potential unit overload issues, high temperatures,
and alarms that may be present. It helps in diagnosing any operational concerns and ensur-
ing the device is functioning optimally.
MRK16 automatically detects the Expansion Board connected so it will show this menu only
if there’s the board inside.
