MTP60 mul-band bodypack transmier
13
*Simultaneous recording and wireless transmission is not available
on transmitters sold in the USA (code: MTP60-US-BT1)
CONFIGURATION
MTP60-<Contry range>
Country range:
EU: 470-832 MHz, Max power 50mW
EUX: 470-832 MHz, Max power 100mW
UK1: 470-663 MHz, Max power 100mW + 960-1075 MHz, Max power 50mW
UK2: 510-698 MHz, Max power 100mW + 960-1075 MHz, Max power 50mW
US*: 470-698 MHz, Max power 100mW + 614-663 MHz, Max power 20mW + 940-960 MHz,
Max power 100mW
CA: 470-608 MHz, Max power 100mW + 614-663 MHz, Max power 20mW + 940-960 MHz,
Max power 100mW
*Simultaneous recording and wireless transmission is not available on transmitters sold in the USA
ANTENNA RANGE & CONFIGURATION
Ant Label Code Band MHz
507
AWF30-B1-507
470-547
590
AWF30-B1-590
547-663
552
AWF30-B3-552
510-595
646
AWF30-B3-646
595-698
710
AWF30-710
663-760
796
AWF30S-796
760-832
808
AWF30-BP-808
806-810
950
AWF30-B8-950
940-960
1k1
AWF30-B6-1K1
960-1160
MTP60 is supplied with
• 2 AA Alkaline batteries
• 1 wire belt clip (BCLW60)
• antenna kit: according to the configuration of MTP60 the following kit antennas are sup-
plied:
MTP60-US and MTP60-CA MTP60-UK2
AWF30-B1-507 (470-548 Mhz) AWF30-B3-552 (510-595 Mhz)
AWF30-B1-590 (548-663 Mhz) AWF30-B3-646 (595-698 Mhz)
AWF30-B8-950 (940-960 Mhz) AWF30-B9-1K1 (960-1160 Mhz)
MTP60-UK1 MTP60-EU and MTP60-EUX
AWF30-B1-507 (470-548 Mhz) AWF30-B1-507 (470-548 Mhz)
AWF30-B1-590 (548-663 Mhz) AWF30-B1-590 (548-663 Mhz)
AWF30-B9-1K1 (960-1160 Mhz) AWF30-710 (663-760 Mhz)
AWF30S-796 (760-832 Mhz) soft
