WisyCom MTP60 - MTP60 Technical Specifications

MTP60 mul-band bodypack transmier
12
TECHNICAL SPECIFICATION
Frequency range
from 470 to 1075 Mhz, depends on the country (see Congurations)
Switchable channels
2400 managed in 40 groups ofr 60 frequencies completely user programmable
Switching-window
Up to 362 MHz, depending on band (see Congurations)
Frequencies
Quartz PLL frequency synthesizer circuit (5 kHz step)
Frequency error
±2.5 ppm, in the rated temperature range
RF Power
10mW/ L10 W/ 20 mW/ L20 mW / 50 mW /100 mW
Antenna connector
LEMO-F 1 pin
Modulation
Wideband and Narrow-band with FPGA based digital signal processing
Nominal deviation
±40 kHz Wideband / ±25 kHz Narrowband
Peak deviation
±56 kHz Wideband / ±35 kHz Narrowband
Spurious emissions
< 2 nW
Telemetry feature
TX transmits also a digitally modulated sub-carrier, suitable for:
• tone-squelch operating
• remote battery monitoring
• optional PTT (push to talk) operation
Noise Reduction system
ENS - Wisycom ultra-high permorfmance compander
AF bandwidth
Audio frequency response (dBa):
• 45 Hz ÷ 17 KHz (3dB) in NarrowBand mode (NB)
• 45 Hz ÷ 20 KHz (3dB) in WideBand mode (WB)
Distortion
< 0.3 % (0.15 % typ.)
SND/D ratio (Analogue)
typ. 115 dB (A)rms with 40 kHz deviation; typ. 121 dB (A)rms with 56 kHz deviation Wideband
typ. 115 dB (A)rms with 25 kHz deviation; typ. 121 dB (A)rms with 35 kHz deviation Narrowband
Audio input connector
LEMO 3pin
Audio input level
from -40 dBu (12mV RMS) to 26 dBu (15.5 V RMS) adjustable in 1 dB steps
Max input level
+26 dBu (15.5 V) at clipping, +20 dBu (7.75 V) at nominal level
Storage media
micro SD memory card (.wav les - BWF)
Time code
Linear Timecode decoding
Bit rate
16 bit / 24 bit / 32 bit
Sampling rate
48 kHz
Managing interface
Bluetooth 5 long range, USB-C, IrDA
LED
2 RGB LEDs (red, green and blue) for audio, RF and battery status.
1 LED for recording, 1 LED for battery charger
Battery level indication
percentage or minute/second
PTT function
Pin 3 of AF connector can be controlled via an externall PTT button
Display
High contrast OLED white display (128 x 64 pixels)
Power supply
2 x AA battery (alkaline, NiMh or lithium) or dedicated lithium batter pack (MPRLBP)
Power consumption
250mA@ 3V average (display off, 100mW power)
Battery life
approx. 10 hours @ 10mW with Alkaline batteries
Temperature range
-10 ÷ +55 °C
Dimensions
75,7mm x 61,4mm x 19,4mm (HxWxD) without clip
Weight
Approx. 140 g. without batteries (183 g. with lithium batt.)
