WiT WT901BLECL BLE5.0 User Manual

WT901BLECL BLE5.0 | manual v23-0420 | www.wit-motion.com
- 30 -
Menu of Calibrate
Button
Function
Acceleration
Accelerometer calibration
Magnetic Field
Magnetometer calibration
Reset Height
Reset height data to 0
(only for sensor built-in barometer,
including WT901B, WTAHRS2, WTHARS1,
HWT901B)
Reset Z-axis Angle
Reset Z-axis angle to 0 degree, not available
for WT901BLECL BLE5.0 in 9-axis algorithm
Gyro Auto Calibrate
Auto-calibration of gyroscope
Menu of Range
Button
Function
Acceleration
Acceleration measurement range
(2/4/8/16g/s2)
Gyro
Gyroscope measurement range
(250/500/1000/2000 deg/s)
Band Width
Bandwidth range
(5/10/20/42/98/188/256Hz)
Menu of Communication
Button
Function
Output Rate
Return rate selection
