EN-47
BPM Core
v1.0 | July 2019
Specifications
BPM Core
• Length: 560 mm (22 in.)
• Width: 165 mm (6.4 in.)
• Height: 450 mm (unfolded) (17.7 in.)
• Weight: 430 g (0.947 lb)
• Cu circumference: fits arm circumferences from 22 to 42 cm (9 to 17 in)
Materials and sensors
• ECG: recorded via two stainless-steel electrodes located inside the cu, and
one on the tube.
• Digital stethoscope: silicone membrane and stainless-steel support
• Display: LED matrix screen
• Pressure sensor: gauge sensor
• Sensor: semiconductor pressure sensor
Connectivity
• Bluetooth and Wi-Fi
Storage and memory
• Free and unlimited storage on Withings cloud
• Up to 6 measurements can be stored on the BPM Core without
synchronization in Bluetooth or Wi-Fi
Technology
• Cu oscillo metric method
• Measurement range: 0 to 285 mmHg, SYS 60 to 230 mmHg
• Accuracy: ±3 mmHg or 2% of reading (pressure) / ±5% of reading (pulse)
• Cu inflation: automatic inflation with air pump at 15 mmHg/s
Certifications
• Medical EC approved (under review to be FDA cleared)
• 2008 ANSI/AAMI/ISO 81060-2:2013, EN ISO 81060-2:2014
• FCC part B 15B: 2013
Internaltional standards
• European Society of Hypertension (ESH) for all countries except USA and
Canada
• American Heart Association (AHA) for USA and Canada
