WiXHC MACH3 MK4-V - Power Supply Wiring

DC 24V-INPUT
DC 0V_GND
NO.1：Offer Power suppl y to card
NO.2：Drive wiring: Support Stepper/Servo drive,Differential output signal
Before using our breakout board, please offer
DC24V power supply to make it works,
Current 0.5A
ChengDu XinHeCheng Technology Co.,Ltd
www.cdxhctech.com
Wiring
DC24V,0.5A
Power supply wiring
