WiXHC MACH3 MK4-V User Manual

Specification
Before make it work, you need to offer DC24V power to our
Breakout board.
Output
MKX-V offer 8pcs expandable Output IO, all IO active low;
Drive current 50mA,Support max 24V signal.
Spindle forward:OUT1：Corresponding MACH3output configuration is P1.0
Spindle reverse：OUT2:Corresponding MACH3 Output configuration is P1.1
Expandable Output IO 3-8：OUT3-8：Corresponding MACH3 Output configuration
are：P1.2-P1.7
MKX offer max support 6 axis drive,MK3-V support 3 Axis, MK4-V support 4
Axis, MK6-V support 6 Axis . 。
MKX support Stepper/Servo drive, support pulse+Directi on output and differential
Output, support max frequency of pulse output is 2000KHZ
Drive current is 20mA
Hardware Instruction
ChengDu XinHeCheng Technology Co.,Ltd
Power Supply
Axis drive port
www.cdxhctech.com
<5>
