MKX Wiring
Spindle connected stepper or servo drives
stepper or servo drives
PUL+
PUL-
DIR+
DIR-
0V
NO.4：
Relay
Output active low,24v\ 50 mA
Output Relay Interface：OUT3 to OUT8 Relay Interface
5V5V
5V and 0V connect
to our card 5V and
0V
