User Manual WMF1500 S
Appendix: Technical data
Appendix: Technical data
Technical data for coffee machine
External dimensions Width 12.8in (325mm)
Height 26.77in (680mm) (with bean hopper)
Depth 23.23in (590mm)
Coffee bean hopper approx.22.93oz (650g) each
(1
Coffee bean hopper in the center
approx. 19.4oz (550g)
(1
Powder hopper (optional) approx.42.33oz (1,200g) each
(2
Weight empty 70.5lb–79.4lb (32–36kg)
(depending on the model)
Water supply 3/8inch hose connector with mains tap, and
filter with 0.08mm mesh size, on site.
At least 29psi (0.2MPa) (2bar) supply pressure
at 0.53gal/min (2l/min).
Maximum 87psi (0.6MPa) (6bar).
Maximum inlet temperature 95°F (35°C).
The set of hoses provided with the new coffee
machine and/or the new water filter must be
used. Do not use old hoses.
Water quality For drinking water with carbonate hardness
above 5gpg (5°dKH), aWMFwater filter should
be fitted upstream.
Water drain tube (optional) Tube aminimum of DN 19, minimum downward
slope of 0.02in / in (2cm/m)
Nominal power rating 1.9kW
Power supply 120V, 60Hz, (1 / N/ PE)
Illumination LED class 1
Degree of protection IP X0
Protection class
Continuous sound pressure level
(Lpa)
< 70dB(A)
(3
We reserve the right to make technical modifications.
(1
The capacity depends on the size of the coffee beans.
(2
Only with optional powder hopper. The fill level depends on the powder used.
(3
A-evaluated sound pressure level Lpa (slow) and Lpa (impulses) at operating personnel workplace is under 70dB(A) in any
working mode.
Installation clearances
