WMF Presto Service Manual

37
WMF presto Service manual edition 08/2007
WMF presto Service Manual
Constant water connection
Parts Part number Amount
Complete constant water connection 3328226199 1
(Supply valve, press. red., flowmeter, hose)
Hose 0000480015 0,78
Flowmeter water tank 3
322503000 -1
Hose (water tank) 0000484948 -0,7
Choc
Parts Part number Amount
Maintenance set 2/06 3328285000 1
Oval choc hopper complete 3
328235000 1
KMP choc/topping drive 3
322517000 1
Drive actuator 3
323215000 1
Topping
Parts Part number Amount
Maintenance set 2/06 3328285000 1
Oval topping hopper complete 3
328248000 1
KMP choc/topping drive 3
322517000 1
Drive actuator 3
323215000 1
9.3.2 Revision routine
Philips screwdrivers short and long
Torque screwdriver TX20
Multitool
Open-end wrenches 8, 12, 14, 15 and 17 mm
Wire cutter, spring circlip pliers
8 and 5.5 mm socket wrenches
Flat nose pliers
9.3.3 Coffee machine revision
Preparing the machine
Open coffee machine
Replace fan and discharge suction hose
Remove safety valves
Remove valves
Remove external boiler parts
Dismantle boiler
Remove external boiler parts (optional)
Dismantle steam boiler
•
•
•
•
•
•
•









