WOERNER PMF - Reservoir Lid Locking Mechanism

Operating manual PMF/GMF Page 19 of 37 B0343
5.3.1 Reservoir lid
Always ensure that the pump is switched off before opening the lid!
Description
The reservoir lid is locked by two fasteners as shown in
this picture.
In normal use both fasteners must be closed.
If it´s necessary to open the lid it is mandatory to follow
the instructions below.
Locking hook
Locking lug
Safety latch (locked)
Safety cover
Locking lever
