Operating manual PMF/GMF Page 26 of 37 B0343
6.4 Power supply and powering-up
6.4.1 Motor
Important! Compare the indications of the local voltage supply with the tech-
nical data of the pump unit.
Important! Lay the mains cable that way to prevent any unintentional tearing
off.
Important! Skilled electricians are the only ones allowed to intervene in elec-
trical installations according to DIN VDE 1000-10.
Connect the pump unit to the voltage supply.
Before starting-up, double-check the installation for correct electrical connection.
Warning!
There is danger to life when intervening into the electrical installations!
Skilled electricians are the only ones allowed to intervene in electrical installa-
tions according to DIN VDE 1000-10.
6.4.2 Hydraulic motor
Important! Compare the pressure of the local hydraulic supply with the techni-
cal data.
Important! Lay all the lines that they are protected from unintentional tearing-
off.
Important! Skilled electricians are the only ones allowed to install connec-
tions.
Connect the pump unit to the hydraulic line.
Before starting-up, inspect the correct installation of the connections.
6.4.3 Oscillating drive
Link the eccentric with the rocker arm of the pump drive. Before starting-up, check the
rocker arm for proper length depending on the eccentric stroke (as for the formula, see
section 3.5.5).
Important! Improperly set-up rocker arm length may lead to damage of the
pump.
