821016: AMPx-E8 Series User Guide
© 2011 Wohler Technologies, Inc. All rights reserved.
15
Chapter 2 System Overview
Rear Panel Connectors
Figure 2–8 The AMP1-E8MDA-3G Rear Panel
Figure 2–9 The AMP2-E8MDA-3G Rear Panel
Note that the DA models do not have SDI connectors.
Power
SDI Option 2
SDI In (1 & 2)
SDI Re-Clocked Out
Reference
AES Bal In & Loop Out
AES/PCM In (1 thru 4)
Analog In
Selected/Downmix
Analog Out (L&R)
AES Out from SDI
RS-232 B
Metered Analog Out
Decoded Dolby E/AC-3 Out
(1 thru 4), Mix, and In (1 & 2)
RS-232C
RS-232 A
OPT 1
Power
RS-232C
SDI In (1 & 2)
SDI Re-Clocked Out
Ref
AES Bal In &
Loop Out
Analog In
Selected/Downmix
Analog Out (L&R)
Remote
Metered Analog Out
AES/PCM In (1 thru 4)
Decoded Dolby E/AC-3 Out
(1 thru 4), Mix, and In (1 & 2)
RS-232A
RS-232B
Opt 1
Balanced AES Out from SDI
Opt 2
