Chapter 6 Setup Menu
Accessing Setup Mode
Accessing Setup Mode
Figure 6–1 Setup Menu Tree
Fn + Setup
Normal Operation
Esc
Enter
Setup: AES Term
Unbal. 1: Ena/Disa
Balanced 1: Ena/Disa
Balanced 2: Ena/Disa
Balanced 3: Ena/Disa
Balanced 4: Ena/Disa
Unbal. 3: Ena/Disa
Unbal. 4: Ena/Disa
Unbal. 2: Ena/Disa
Bitstrm. 1: Ena/Disa
Bitstrm. 2: Ena/Disa
Save and Exit
Enter/Esc
Setup: AOutputPref
Discrete
Downmix
Enter
/Esc
Enter/Esc
Setup: Startup ++
Last Used
SDI 1
SDI 2
BSt 1
BSt 2
AES 1
AES 2
Analog
SDI 1 + DBY
SDI 2 + DBY
Enter
/Esc
Setup: Srnd Gain
Mute
-9 dB
-6 dB
-3 dB
Enter
/Esc
Setup: Erase PSet
0 through 9
Enter
/Esc
Setup: Pset Mode
Enable
Disable
Enter
/Esc
Unused?
No
Choose Preset Num
Preset0: DOLBY1
AES2 ?@<A>BC
Name: A_
OVERWRITE PRESET?
Preset1: DOLBY1
Save Old Name?
Preset1: DOLBY1
Enter
Esc
Enter
Esc
Setup Menu
AES Term
Startup
Srnd Gain
Erase Preset
Pset Mode +
Save Preset
AOutPref
RCallPSet +
Choose Preset Num
Preset0: AES MIX
Enter/Esc
ERASE PRESET?
Preset0: AES MIX
Enter/Esc
Choose Preset Num
Preset1: On Site
0 through 9
Normal
Normal
Normal
Enter/Esc
Enter
Yes
Enter
/Esc
SDI Delay
Setup: SDI Delay
Off through 170 ms
Enter
/Esc
A Vld Det
A Vld Det
Ena/Disa
Enter/Esc
Phase Bts
Phase Bts
Ena/Disa
Enter
/Esc
