Chapter 7 Features and Specifications
Features
Features
Common Features
The AMPx-E8 Series audio monitors provide a complete, exceptionally
high quality Dolby E, Dolby Digital (AC-3), 3G/HD/SD-SDI, PCM and
analog stereo audio monitoring solution. A significant feature is the
ability to process and monitor up to eight channels from a Dolby E or
Dolby Digital (AC-3) bitstream, a 3G-SDI, HD-SDI and/or SD-SDI
bitstream, two sets of four AES/EBU signal pairs (balanced and
unbalanced) or eight analog channels. Eight high-resolution,
53-segment, tri-color, LED bar graph audio level meters provide
accurate and instantaneous visual level monitoring at a glance.
• Space-saving 2 RU
• Dolby E, AC-3, AES/EBU, and analog signal monitoring
• Four de-embedded AES balanced or unbalanced outputs
• (Eight channels) from two selected SDI groups
• Four AES/EBU balanced inputs and loop-throughs on a DB-25
connector
• Eight analog inputs on a balanced DB-25 connector
• Eight analog outputs on a balanced DB-25 connector
• Comprehensive multi-channel to stereo downmix capability
• Unit configuration stored while unit is switched off
• Storage for ten preset monitoring settings for easy recall
• Phase (polarity) correlation display of selected channels
• LCD status display on front panel
• Volume and balance controls
• Eight high-resolution 53-segment tri-color LED bar graph level
meters with simultaneous PPM dot over VU bar
