821016: AMPx-E8 Series User Guide
© 2011 Wohler Technologies, Inc. All rights reserved.
39
Chapter 3 Audio Configuration
Setting the Monitor’s Startup Configuration
Setting the Monitor’s Startup
Configuration
You can configure the AMPx-E8 Series monitor to start up from a
powered-off state, and automatically begin monitoring a particular
input.
1. Press the Fn + Setup buttons.
2. Press the Down button until the LCD screens Startup as shown
in Figure 3–13 below.
Figure 3–13 Startup Menu Option
3. Press the Enter button to display the Startup list.
4. Press the Up or Down buttons to scroll through the startup
options. Note that only those options that are available in your
system will show up in the list.
• Last Used
• Analog
• AES 1
• AES 2
• SDI 1
• SDI 2
• BSt1
• BSt2
• SDI 1 + DBY
• SDI 2 + DBY
5. Press the Enter button to make your selection and return to the
Setup Menu.
6. Press the
Escape button to return to normal operation.
848131 3.03
Setup: Startup
