Chapter 7 Features and Specifications
Specifications
Power Output
High Frequency
Low Frequency
6 W RMS (each channel)
14 W RMS
Converted Analog Out THD <0.008%
Magnetic Shielding <1 Gauss any adjacent surface
Inputs
• AES (D-Sub 25, 4 BNC)
• 3G/HD/SD-SDI (2 BNC)
• Analog (D-Sub 25)
• Dolby (2 BNC)
Outputs
• Metered Analog (DB-25)
• 3G/HD/SD-SDI Re-Clocked
(BNC)
• AES Unbalanced Out from SDI
(HD-15)
• (Optional) Balanced AES Out
from SDI Input (DB-25)
• Selected Downmix/Analog Out
(Left and Right, XLR-M)
• AES Bal In/Loop Out (DB-25)
Power Consumption 72 max
AC Mains Input 100 to 240 VAC, 50 to 60 Hz
2RU Model Chassis
Dimensions
3.5” H x 19” W x 12.5” D
(89 mm x 483 mm x 317.5 mm)
(Depth, including controls and
knobs, is 14” [355.6 mm])
1RU Model Chassis
Dimensions
1.75” x 19” x 11”
(4.5 mm x 483 mm x 30 mm)
(Depth, including controls and
knobs, is 13.5” [342.9 mm])
Shipping Weight
1 RU: 18 lbs. (8.20 kg)
2 RU: 22 lbs. (9.98 kg)
a Other level meter scales are available at time of manufacture including BBC,
DIN, and others. Contact Wohler for more information concerning alternate
scales.
Table 7–2 Specifications for the AMPx-E8 Series
Monitors
Specification Value
