Wolf ART - Electrical Connection

6
3
1526
4
+ -
Plug to the
top part
Telecontrol contact
for eBUS and SCOM
Connection
data cable
e-BUS or SCOM
The electrical connection must only be carriedThe electrical connection must only be carried
The electrical connection must only be carriedThe electrical connection must only be carried
The electrical connection must only be carried
out by a qualified electrician.out by a qualified electrician.
out by a qualified electrician.out by a qualified electrician.
out by a qualified electrician.
Do not Do not route these cables with mains
supply cables.
Electrical connection
Wire the ART with 2-core cable (minimum cross-
section 0.5 mm²) to the gas fired boiler. Subject
to boiler terminal strip, select one of the adjacent
wiring diagrams.
Warning
Replace the ART onto its base and click into place.
When refitting the housing ensure, that the
contact pins on the thermostat are not bent.
Terminal strip inside the ART base
ART terminal
strip
Terminal strip
on the gas
fired boiler
Connection version a)
ART terminal strip
Terminal strip
on the gas
fired boiler
1 2
+ -
Zubehör
+
-
a
b
AF
24VAC 24VDC
Connection version b)
ART terminal strip
Terminal strip
on the gas
fired boiler
1 2
+ -
Zubehör
!
+
-
a
b
AF
24V
0V
24VDC24VDC
Connection version c)
1 2
+ -
ab+
A
AF
F
24 V
E1
eBUS
Accessory
Accessory
